FANUC Robot M-20iB
| FANUC Robot M-20iB | M-20iB/25 | M-20iB/25C | M-20iB/35S | |
| Controlled axes | 6 | |||
| Max. payload at wrist | 25kg | 35kg | ||
| Motion range (X, Y) | 1853mm, 3345mm | 1445mm, 2591mm | ||
| Repeatability | ±0.02mm | |||
| Mass | 210kg | 205kg | ||
| Installation | Floor, Upside-down, Angle | |||
| Matching controller / Input power capacity | R-30iB/R-30iB Plus (A-, B-cabinet), R-30iB Mate/R-30iB Mate Plus (standard) / 3kVA | R-30iB Plus (A-, B-cabinet), R-30iB Mate Plus (standard) / 3kVA | ||
| Application | Handling | x | x | x |
| Assembling | x | x | x | |
| Arc welding | x | - | x | |
| Sealing | x | - | x | |
| Clean room | - | x | - | |
| Others | Mold handling, Deburring | - | Mold handling, Deburring | |
品牌 FANUC （发那科）
品名 多功能智能小型机器人
型号 FANUC ROBOT M-20iB
品名 多功能智能小型机器人
型号 FANUC ROBOT M-20iB
